AdvanLED All-in-One Solar LED Street Light
The AdvanLED All-in-One Solar LED Street Light is an innovative solution that harnesses the power of the sun to provide efficient and sustainable lighting. This street light integrates the solar panel, lithium battery, controller, and LED lamp into a single unit, eliminating the need for any cable works. With this all-in-one design, installation and maintenance become hassle-free. The AdvanLED Solar LED Street Light is not only environmentally friendly but also cost-effective, as it requires no electricity from the grid.
Advantages :
- Excellent heat dissipation
- All-in-one design, easy for installation and adjustment
- Ultra high Efficiency up to 200 lm/W System Level*
- 2 Days Autonomy Battery Capacity
- High Efficiency Monocrystalline Solar Panel
| Model No. | AVL-ASSL-xxx-yyK G1 |
| Power(W) | 20, 40, 60, 80, 100 |
| Input Voltage(V) | 12 |
| Efficiency(Lm/W) | 190-200* |
| Lumen flux(Lm) | 4000, 8000, 12000, 16000, 20000 |
| Color temperature: | 3000K / 3500K / 4000K / 5700K / 6500K |
| CRI | ≥70 |
| IP protection | IP65 |
| Days for rainproof / Autonomy | ≥2 days |
* At Model No., xxx refers to : 020, 040, 060, 080, 100
* At Model No., yyK indicates CCT: 30 = 3000k, 35 = 3500k, 40 = 4000k, 57 = 5700k and 65 = 6500k
| Model No. | AVL-ASSL-xxx-yyK G1 |
| Max power | 45W, 60W, 100W, 165W, 165W |
| Voltage | DC18V |
| Material | Mono-crystalline |
* At Model No., xxx refers to : 020, 040, 060, 080, 100
* At Model No., yyK indicates CCT: 30 = 3000k, 35 = 3500k, 40 = 4000k, 57 = 5700k and 65 = 6500k
| Model No. | AVL-ASSL-xxx-yyK G1 |
| Voltage(V) | 12.8 |
| Battery Module Capacity(AH) | 20, 40, 60, 80, 80 |
| Battery Type | LiFePO4 Battery |
| Cable(mm²) | 2*1.5mm² |
| Working Temp(°C) | Power charge: 0°C – 45°C Power discharge: -20°C – 55°C |
| Cycles | ≥1500 times |
| Charging time | 6-8H |
| Discharge time | >12 hours/night |
* At Model No., xxx refers to : 020, 040, 060, 080, 100
* At Model No., yyK indicates CCT: 30 = 3000k, 35 = 3500k, 40 = 4000k, 57 = 5700k and 65 = 6500k
| Model No. | AVL-ASSL-xxx-yyK G1 |
| Current(A) | 10 |
| Mounting | Side entry or post-top |
| Motion+timing mode | 2H 100% ;2H 50% ;8H detected 100% ,none 30% ;(Adjustable) |
* At Model No., xxx refers to : 020, 040, 060, 080, 100
* At Model No., yyK indicates CCT: 30 = 3000k, 35 = 3500k, 40 = 4000k, 57 = 5700k and 65 = 6500k
New Generation LED’s
New generation high bright SMD, combined with integrated lens and lower current, which increases lumen flux by 10% and decreases light attenuation.
Secondary Optical Design
Secondary optical design, specially for solar street light, which maximally balances uniformity and illumination, while decreasing dispersion and reducing the color reproduction.
Lithium Battery
High energy density A-level batteries, combined with new protection plates and temperature control protection, which are safer and of longer cycling life. LiFePO4 battery optional.
Solar Panel
Top quality monocrystalline silicon wafer, while improving packaging materials and technology, upgraded light transmittance, anti-aging performance and power generation capacity.
MPPT Charging Technology
The MPPT controller maximizes power of the battery board, which improves the energy utilization rate by 15% ~ 20% compared with the ordinary controller.
Road Lighting Design
Specially designed lighting profile allows our Integrated Solar LED Street Light to achieve different road lighting standards up to ME2.
